DATAEAGLE Compact 3333A / 3343A – Wireless Profibus

DATAEAGLE 3000 – WIRELESS PROFIBUS

Patented filter technology for PROFIBUS

Plug and Play – no configuration necessary

DATAEAGLE Compact 3333A / DATAEAGLE Compact 3343A

The DATAEAGLE Compact 3333A / 3343A series was specially developed for the transparent transmission of PROFIBUS DP. By using 869 MHz or 915 MHz, particularly high ranges of up to 3 km can be achieved. The patented pre-processing enables reliable wireless data transmission without radio interruptions and thus prevents system downtimes.

Optimized for PROFIBUS DP
Plug and Play – no device configuration necessary
Use in Europe (869MHz) and America (915MHz)

Download product information here

to product downloads

Technical DAata – DATAEAGLE Compact 3333A / 3343A

Weight	0,16 kg
Protocol	PROFIBUS
Voltage supply	24 V DC
Connection voltage supply	Terminal clamps
Power consumption	200 mA
Mounting	DIN rail mounting
Conformity	CE, FCC
IP rating	IP20
Temperature range	-20…+60 °C
Frequency	869 MHz, 915 MHz
Maximum number of Radio Slaves	4
Typical Distance (m)	3000
Maximum PROFIBUS DP Transmission rate	1.5 MBit/s
Interface port	9 pol. SUB-D
Maximum number of PROFIBUS DP Slaves	4
PROFIsafe	No
